Fiberglass FRP Dog Bone for Dry

Basic Info.

Model NO.	Fiberglass FRP Dog Bone for dry-type transformer
Material	Fiberglass, Fiberglass and Epoxy, Fiber Glass Yarn
Maximum Voltage	20KV~100KV
Thermal Rating	200 200
Production	Fiberglass Yarn and Epoxy Resin
Product Name	Dry Type Transformer Part Fiberglass Dog Bone
High Temp	200ºC
Sample	Sample Avaliable
Length	1m, 3m or as Design
Density	1.75~1.95 G/Cm2
Rated Voltage	35kv or Above
Insulation Class	F (155°c ) & H (180°c )
Type	Solid
Chemistry	Inorganic Insulation
Classification	Inorganic Insulation Material
Certification	ISO9001
Brand	Xincheng
Transport Package	Wooden Case
Specification	I, H, L, etc
Trademark	XINCHENG
Origin	China
HS Code	48230000
Production Capacity	3000kg/Day

Product Description

Specifications
Place of Origin: China (Mainland) Brand Name: XINCHENG
Product name: dry type transformer part fiberglass dog bone Material: fiberglass and epoxy
Name: fiberglass dog bone Usage: dry type transformer
Application: High Temperature, dry-tape transformer, reactor
Rated Voltage: 35kv or above Tensile Strength: 89.7Mpa
Size: 6*8, 8*8, 8*10, 10*10mm or customize Shape: I,H,L ,etc or customize
long: 6mm,8mm,10mm,16mm,20mm or customize width: 4mm,6mm,8mm or customize
Color: White , red, yellow, grey, green, black,etc. Density: 1.75~1.95 g/cm2
Other Size: Customized as per customers' require Feature: High Temperature Resistance
Insulation class: F (155°C ) & H (180°C ) Surface Treatment: polished, extruded on the surface
Production: fiberglass yarn and epoxy resin Sample: Sample Available
Shape: square, rectangular, circle, L-shape Length: 1m, 3m or as design
Standard: GB/T5591.3.1-2008 Certification: SGS
OEM,ODM service: Available Virtue: UV-protection, Heat-protection


1.FRP Pultrusion:
Pultrusion is a continuous process for the manufacture of products having a constant cross section, such as rod stock, structural shapes, beams, channels, pipe, tubing, fishing rods, and golf club shafts. Pultrusion produces profiles with extremely high fiber loading, thus pultruded products have high structural properties.
Pultrusion is a manufacturing process for producing continuous lengths of FRP structural shapes. Raw materials include a liquid resin mixture (containing resin, fillers and specialized additives) and reinforcing fibers. The process involves pulling these raw materials (rather than pushing as is the case in extrusion) through a heated steel forming die using a continuous pulling device. The reinforcement materials are in continuous forms such as rolls of fiberglass mat or doffs of fiberglass roving. As the reinforcements are saturated with the resin mixture ("wet-out") in the resin impregnator and pulled through the die, the gelation (or hardening) of the resin is initiated by the heat from the die and a rigid, cured profile is formed that corresponds to the shape of the die.
FRP Epoxy Insulation Dogbone and Corner piece for transformer are the composite material with unique characteristics, which is produced by the process of drawing and extruding without alkali glass fiber impregnated thermosetting resin. Most rods are composed of polyester resin and fiberglass. These composites can be formed into practically any shape by using the pultrusion process, it has the advantages of high mechanical strength, excellent electrical properties, flame retardant, corrosion resistance, arc resistance, dimensional stability, long life cycle etc.

2.Material : Fiberglass roving with epoxy resin or polyester resin
3.Advantage:
Good dimensional stability
Good high and low temperature resistant
Good Electric Performance
Good Corrosion Resistant
Good Surface Properties
4.Application :
Insulation pultrusion profiles are widely used in railway ,subway ,tramway ,Power
electrical insulation ,cable tray channel,ladders,reinforce core for cable;rib
structure for green house,drain channel, water transporting system ,tooling
handles,sport apparatus, garden facilities ,structure for shelters,removable
housed and refrigerate vehicle shelf.

5.Description:
we can offer many dog bones, like T profile, moulded compunds, I section, bog bone, E section, L section, rectangle profile, etc.
1).it is class F and H insulation material.
2).Regular size: 8x10x108, 8x10x133 , 6x6x130 , 8x8x155,we can also offer according to request
3).High mechanical strength
4).Excellent electrical isolation
5).color: red, black, white, yellow, blue, green, white, gray
6).Application: use in a variety of electrical products, like transformers, chocks, switchgears, lightening arrestors, cable trays, and motor wedges
Such as: T profile, moulded compunds, I section, bog bone, E section, L section, rectangle profile, etc


Specification

Technical Data

Epoxy insulation Dog bone features:
1).it is class F and H insulation material.
2).size: 8x10mm, 6x6mm, 4×8mm,18×20mm, 10×16mm, 16×16mm etc. Any profile can be designed according to customers' requirement.
3).High mechanical strength with light weight
4).Excellent electrical isolation properties with corrosion resistant
5).color: white, yellow, red etc.
6).Longevity of service, non-maintaining
7).Steady whole performance
8).Anti-ageing
9).Well insulated


FAQ
Q1: How about MOQ?
MOQ is according to different products. Whatever you need, we are glad to quote best price with good quality.
Q2: Can you send samples for testing?
Samples are free supplied, but express freight should be taken by client. After making order, we'd like to return freight back.
Q3: How can you guarantee the quality of mass goods is same as the sample sent to me before?
We kept another same sample and marked on company when we sent to customer. So our production will be based on.
Q4: Which package do you use?
Package is important part to avoid goods breaking in transportation. We will choose suitable packing depend on materials.
Q5: When customer respond quality issues after pick up goods, how to deal with?
1) Customer could supply photos of issued goods for our sales staff and then we'll verify which part is wrong.
2) If the issue is confirmed, company will negotiate with customers and compensate in coming orders.


Packaging & Delivery
1. For small size, could be cutted and packed with plastic bag and carton and pallet.
2. For long length like 2m product, wrapped with film, then palletized.
Delivery Time: Around 7-20days upon order confirmed

Our service:
1. Our sales representative are 24 hours online, to ensure reply you ASAP.
2. When the products are finished, they must be checked by our QC firstly.
3. We own several whole production lines, which can not only provide best quality and competitive price, but also reduce production period.
4. Urgent Orders can provide overtime production.
5. We can support OEM & ODM, and can be customized according to the detailed requirement, Like samples or sketches.




Please Contact Us
Miss: lydia
Mob: 86-13752439076 Fax: 86-22-60863016
http://chinainsulation.en.made-in-china.com

Properties	Unit	Standard	Specified value	Obtained value
Water absorption	%	ASTM-D 570-81	0.2 MAX.	0.007
Sp. Gravity at 270 c		ASTM-D 792-91	2 2	2.2
Sp. Gravity at 270 c	Kg/ cm2	ASTM-D 638-91	7500	10715
Impact strength	KJ/m2.	ASTM-D 256-2003	400 min	>408
Arc resistance,sec		ASTM-D-495-99		186
Compressive strength(axial)	Kg/cm2.	ASTM-D 695-91	4000	6248
Flexural strength	Kg/cm2	ASTM-D 349-78	5000	9550
Comparative tracking index	CTI VOLTS	IES 60112-2003	600 min	>600
Di-electric strength proof axial	KV / mm	ASTM-D 149-97a	50 KV/25 min.	66
Di-electric strength proof radial	KV/mm	ASTM-D 149-97a	10 KV / MM	15
Insulation resistance	ohms	ASTM-D 257-92	1 x 1010	1.9 x 1015
Martens heat distortion temperature	0C	DIN 53462 1987	MIN 200	>210
Splitting resistance,n		IS10192-82, Appendix D	4000	5346
Glass content	%	BS-4994 1987	80 5	82

No.	Item		Unit	Value
1	Apparent density		g/cm3	1.95
2	Bending strength		MPa	668
3	Impact strength		MPa	405
4	Insulation resistance	Normal temperature	MΩ	4.5×107
		In water in 24 hours		4.5×107
5	Electrical strength( in oil at 90ºC)		KV	46
